Magnetic core high frequency in-line electronic current transformer EE22
Products are widely used in a variety of switching power supplies, LED power supplies, mobile phone charging power supplies, intelligent charging power supplies, etc.
Magnetic core high frequency in-line electronic current transformer EE22
What are the uses of high frequency transformers? What is the reason for the low number of turns
What is the use of high frequency transformer?
use:
1. To improve the conversion efficiency, use the power supply of a high-frequency transformer. Since the power tube works in an instant on-off state, that is, a state of continuous conversion when one is on and one off, we call it "switching power supply". The loss is about 30% lower than the traditional iron core transformer. Unfortunately, the failure rate is relatively high.
2. It can transform high-frequency pulses. The iron core of ordinary transformers does not have the high permeability of ferrite cores. can't do it
3. Improve the conversion efficiency, use the power supply of the high-frequency transformer, because the power tube works in an instant on-off state, that is, a state of continuous conversion when one is on and one off, so we call it "switching power supply". The loss is about 30% lower than the traditional iron core transformer. Unfortunately, the failure rate is relatively high. What can be learned from is the comparison of old-fashioned ballasts and electronic ballasts
Why is the number of turns in a high frequency transformer so small?
The transformer winding is an inductive device, and its inductance L is a proportional function of the number of turns when the magnetic core is fixed. When the magnetic core and winding of the transformer are fixed, the inductance is fixed.
The current in the inductor I=U/RL
Where RL is the winding inductive reactance = 2x3.14xPxL where P is the power supply frequency, that is to say, the higher the frequency, the greater the inductive reactance. When the frequency is high, very few windings will produce a large inductive reactance without short-circuiting, so It is said that the higher the frequency, the fewer turns will be.
The transformer winding is an inductive device, and its inductance L is a proportional function of the number of turns when the magnetic core is fixed. When the magnetic core and winding of the transformer are fixed, the inductance is fixed.
Magnetic core high frequency in-line electronic current transformer EE22
| Specifications | EE22 vertical plug-in |
| Product material | Magnetic core/Bakelite frame/enamelled copper wire |
| Product Size | 23mmx18mmx17.5mm |
Product dimensions are as follows:
We are a professional manufacturer of high frequency transformers, low frequency audio transformers, inductors, coils and Ethernet transformers. The company directly OEM manufacturing. Advanced production technology. An independent team of engineers. Check the drawings. Provide quotation. Write the processing process and guide the production. Please feel free to purchase. Business cannot be without credibility. We are chosen for credibility and confidence, and we can trade with confidence. Reliable
1. Are you a trading company or a factory?
We are a factory, established in 2011, one of the leading companies of inductors and transformers in China.
An independent team of engineers, advanced production and testing equipment, escort your quality.
There is stock for in-stock products.
For customized samples, 5-10 days.
For mass order, 15-30 days depends on quantity and stock of raw materials.
Price depends on product specification, quantity, market factors.
A price list is available when contacting us.
Business licenses, ISO, SGS, RoHS certificates or export documents, you can get everything you need to keep your money and goods safe.
A bank account is preferred. Western Union, PayPal or other methods are also acceptable.
Our corporate culture is that we are responsible for the quality of our products for life.
Deliver the goods safely to your hands with high-quality export packing cartons and protective packaging methods. We have more than 10 years of packaging experience, whether it is air, sea or truck transportation. Also, if anything goes wrong, shipping insurance is a good option.
|
