| Brand Name: | ZXY |
| Model Number: | ZXY-NR6020 |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | 1000pieces / Reel, size:380mm*325mm*345mm |
| Payment Terms: | T/T paypal xtransfer |
10uH Chip Power Inductor are also known as power inductors, high current inductors. The characteristics of the chip inductors are that the flat bottom surface is suitable for surface mounting. Excellent end face strength and excellent solderability.
1. The magnetic glue coating structure is adopted, which greatly reduces the buzzing sound;
2. The electrode is directly metallized on the ferrite core, which has strong anti-drop impact and is durable;
3. Closed magnetic circuit structure design, less magnetic leakage, strong anti-EMI ability;
4. Under the same size condition, the rated current is 30% higher than that of traditional power inductors;
5. Small size, low profile, save space and save power;
6. Application range of 10uH Chip Power Inductor: LED lighting; multi-function mobile phones; flat-panel TV; Blu-ray DVD; set-top boxes; notebook computers, desktop computers, servers, graphics cards; portable, personal navigation systems, multimedia equipment;
| TYPE | A | B | C | D | E | F | G | H | Fig |
| ZXY-NR6020 | 6.0±0.3 | 6.0±0.3 | 2.1 Max | 2.3±0.3 | 1.85±0.3 | 2.4 | 1.8 | 5.7 | 2 |
| Item | Value |
| Model Number | 10uH Chip Power Inductor |
| Place of Origin | China |
| Application | Notebook,Server,audio and other equipments |
| Brand | ZXY |
| Supplier Type | Original manufacturer |
| Tolerance | ± 20% |
| Operating Temperature | -40℃~+125℃ |
| Rated Power | 100KHz |
|
