| Brand Name: | ZXY |
| Model Number: | ZXY-EI66 |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | 100pieces / Carton |
| Payment Terms: | T/T,Paypal |
1. Material composition
--Core material: High quality silicon steel sheets with high magnetic permeability are commonly used. Silicon steel sheets have the characteristics of low hysteresis loss and low eddy current loss, which can efficiently guide and concentrate magnetic flux, greatly improve the electromagnetic conversion efficiency of transformers, reduce the heating phenomenon caused by hysteresis and eddy current in the iron core during operation, and ensure the stable operation of transformers. For example, in small equipment that works continuously for a long time, silicon steel sheet iron cores can reduce energy loss and maintain stable power supply for the equipment.
--Winding material: High purity electrolytic copper is usually used. Copper has good conductivity, which can reduce winding resistance, minimize energy loss during transmission, and improve the electrical performance of transformers. Moreover, its excellent thermal conductivity helps the winding dissipate heat quickly during operation, ensuring that the transformer can work normally even under high loads and extending its service life.
--Insulation materials: To ensure the safe operation of transformers, various insulation materials are used between windings and iron cores, as well as between windings. Materials such as polyester film and insulation paper have good electrical insulation properties, which can effectively prevent current leakage and short circuit phenomena. At the same time, they also play a mechanical support and protection role to a certain extent, improving the reliability of transformers.
2. Function Introduction
--Voltage conversion: One of the main functions of the EI66 small power transformer is to achieve voltage conversion. By designing primary and secondary windings with different turns ratios, the input AC power can be converted into different voltage levels required by the equipment. For example, reducing the mains voltage to a low voltage that can be used by small electronic devices such as mobile phone chargers, small desk lamps, etc., to meet the working requirements of the internal circuits of the devices.
--Electrical isolation: Transformers operate based on the principle of electromagnetic induction, with no direct electrical connection between the primary and secondary windings, thus achieving electrical isolation between the input and output circuits. This function is extremely important in electronic devices, which can effectively avoid damage to the equipment caused by electrical faults due to current surges, while also improving the safety of the equipment and preventing the risk of electric shock to users.
--Power transmission: Within the rated power range, the EI66 small power transformer can efficiently transmit input power to the output end, providing stable power support for load devices. It can flexibly adjust the output current and voltage according to the power requirements of the device, ensuring the normal operation of the equipment. For example, in small audio equipment, transformers can stably provide the required power to the amplifier circuit, ensuring clear and stable sound quality.
| Application Areas | Applications |
| Consumer Electronics | - Mobile Phone Chargers: Steps down the mains voltage to a suitable level for charging mobile phones. Its compact size makes it easy to be integrated into small - sized chargers. - Portable Audio Players: Provides the necessary power supply with stable voltage output, ensuring high - quality sound reproduction. The high - efficiency operation helps to extend the battery life of the players. - Smartwatches and Wearable Devices: Used in the chargers or internal power conversion circuits. The low - power consumption and compact design are well - suited for these small - sized, power - sensitive devices. |
| Industrial Equipment | - Small - Scale Control Panels: Supplies power to various control components such as relays, sensors, and microcontrollers. Its reliable performance under industrial conditions, including electrical noise and vibration, ensures the stable operation of the control system. - Laboratory Equipment: For devices like small centrifuges, incubators, etc., where a stable and precise power supply is required. The EI66 transformer can accurately provide the specific voltage and current needed for these instruments to function properly. - Automated Small - Parts Assembly Machines: Powers the motors and control units. Its ability to handle short - term overloads during machine startup or sudden load changes is beneficial for maintaining the continuous operation of the assembly process. |
| Communication Equipment | - Wi - Fi Routers: Used to convert the input voltage to the appropriate levels for different components within the router, such as the processor, radio modules, and Ethernet ports. The low electromagnetic interference feature helps to ensure stable data transmission without interfering with the wireless signals. - Small - Cell Base Stations: Provides a stable power source for the base station's electronics. Its compact and lightweight design is advantageous for installation in areas with limited space, and it can maintain stable operation even under fluctuating input voltages. - IP Cameras: In the power supply units of IP cameras, it steps down the voltage and provides electrical isolation, protecting the camera from electrical surges and ensuring continuous video surveillance. |
| Medical Devices | - Portable Medical Monitors (e.g., Blood Pressure Monitors, Glucose Meters): Supplies power to the device's circuitry. The high - quality insulation materials used in the EI66 transformer ensure safety in medical applications, preventing electrical leakage that could harm patients. - Small - Scale Diagnostic Equipment: For devices like portable ultrasound scanners used in clinics. The stable power output of the transformer is crucial for accurate diagnostic results, as any power fluctuations could affect the performance of the sensitive imaging components. |
|
